Waterproof Solar Mounting Frame Roll Forming Machine

Customized for American customers

Availability:

Quantity:



Inquire Add to Basket

Brand:
BMS

Quick Details

Profile

No.	Main Parameters		Roll Forming Mill Parameters
1.	Material Thickness	0.8-1.2mm	Forming Stations	22 stations
2.	Feeding Width	392mm	Body Frame	H450
3.	Application Material	Aluminum magnesium zinc plate	Side Wall Thickness	18mm
4.	Electrical Standard	380V50Hz/3Ph	Shaft Diameter	45# Steel, φ70mm
5.	Cutter material	Cr12MoV	Main Motor Power	11KW
6.	Yield Strength	420Mpa	Screw Bolts	Grade 8.8
7.	Forming Speed	10-15m/min	Effective Width	According to the drawing
8.	Control System	PLC Control System	Roller	Cr12 ,precision machined
9.	Hydraulic Motor	5.5KW	Machine Color	Blue+Black+Orange
10.	Testing Material	BMS Will Provide The Size of Feeding Material to Purchase that 2 Weeks Before Machine Testing

Machine Components Display

Feeding Device

Main Roll Forming Mill

Post Cutter

Post to cut, stop to cutting, Two pieces type of cutting blade design, no blanking
Hydraulic motor: 5.5KW
Cutting tool material: Cr12MoV(= SKD11 with at least one million times of cutting life), Heat treatment to HRC58-62 degree
The cutting power is provided by the main engine Independent hydraulic station
