High Speed U Channel Roll Forming Machine (45-65M/min) YX25-45/55/65

This machine exports to many countries, the most important is that all you need can be customized.
Availability:
Quantity:
Inquire Add to Basket

  • YX25-45/55/65

  • BMS

Quick Details

Profile

                         版型图1


No.               Main Parameters                  Roll Forming Mill Parameters
1. Material Thickness

0.4-0.6mm

 Forming Stations

12-step
2. Version Size Tolerance

 ±0.5mm

(Shape Tolerance)

 Base H450, Rectangular Tube
3. Application Material

 Galvanized Coil

 Side Wall Thickness

 Q235 t18mm
4.

Archway Structure

35

 Shaft Diameter 40# Steel, φ50mm
5.

Manual Decoiler

3T-300 Provided by Yourself

 Main Motor Power

 5.5 KW
6. Yield Strength

550Mpa

 Screw Bolts Grade 8.8
7.

Oil Pump Motor

4 KW

Chain

ZIQIANG
8. Effective Width As Customer Design Product Speed

40m/min
9. Control System PLC Control System   Roller

Cr12, CNC Lathes, Hear Treatment, HRC58-62
10. Length Tolerance ±1mm（6M） Reducer

K Series
11. Testing Material

BMS Will Provide The Size of Feeding Material to Purchase that 2 Weeks Before Machine Testing



Work Flow

Decoiler (Provided by Yourself) → Feeding Guide Device →  Roll Forming → Hydraulic Post Cutting Device (Non-stop) →

Hydraulic System → PLC Control System → Exit Rack

1


Machine Components Display


Feeding Device             Hydraulic Station


         Feeding Device                          Hydraulic Station



  Post Cutter             Profile Application Case



            Hydraulic Post Cutter                                                                 Product Application Case





Machine Produced Products

Main Roll Forming Mill箭头Profile Application Case1


详情页_03

详情页_04

详情页_05图片1
